- Standalone sequential sampling system with max. 16 filters
- Inlets are not included
- According to USEPA 40 CFR Part 50 / Compliant with EN12341:2014
应用
- Standalone sequential sampling system with max. 16 filters
- Inlets are not included
- According to USEPA 40 CFR Part 50 / Compliant with EN12341:2014
- Settable flowrate 1 m³ /h (16.67 l/min) or 2.3 m³ /h (38.34 l/min), accuracy < 2 %
- Mechanical changer
- Vacuum pump 4 m³
- Stainless steel housing, aluminum suction tube
- Linux controller with 7'' touch LCD and jog dial
- Data transmission via USB, RS232,3G/4G
- Sensors for ambient temperature, rel. humidity, air pressure and filter pressure
- 2 magazines with total 31 filter cassettes 47 mm
- Dimensions without tube (H x W x D): 1060 x 460 x 260 mm
- Weight without inlet: appr. 42 kg
- Protection index: IP65
*Optional: Active cooling (50W) for filter storage < 23 °C
*Optional: Integrated RFID reader & writer for filter identification
*Optional: Derenda IOT cloud solution with online remote and monitoring
